Product Name
|
Dump Truck
|
| Chassis Model |
JH6 |
| Drive Type |
6×4 |
| Steering |
Left Hand Drive / Right Hand Drive |
| Wheelbase(mm) |
3700+1350 / 3800+1450 / 3900+1350 / 4100+1350 / 4300+1350 / 5300+1350 etc
|
| Frame(mm) |
300×80×(8+5) / 300×80×(8+8) / 300×80×(8+8+5)
|
| Rear Axle Ratio |
4.875 / 5.263 / 5.291 / 6.733 |
| Front Axle |
2020 / 2055 |
| Rear Axle |
Φ300 Cast steel (improved iron) wheel reduction bridge
|
| Engine Brand |
FAWDE / WEICHAI |
| Number of cylinders |
6 |
| Cylinder Type |
In-line |
| Displacement |
11.05L / 12.5L |
| Emission Standard |
Euro 2 / Euro 3 / Euro 5 / Euro 6 |
| Horsepower |
340HP - 500HP |
| Transmission Brand |
ZF / FAWDE / FAST |
| Transmission Type |
Manual / Automatic |
| Forward Shift Number |
12 |
| Reverse Shift Number |
2 |
| Cabin |
Flat roof / High roof |
| Cabin width(mm) |
2550 |
| Passengers |
2 |
| Seating Row |
One row and a half |
| Driver's Seat |
Air conditioner |
| Fuel Tank Material |
Steel / Aluminium |
| Fuel Tank Capacity |
400L / 600L |
| Number of tires |
10 |
| Tires |
12.00R20 ; 12.00R24 ; 13R22.5 ; 295/80R22.5 ; 315/80R22.5 etc
|
